Computer Interface Unit

Name: Computer Interface Unit
Brand: INNOVATIVE SYSTEMS
Price: 50000.0 INR
Availability: InStock

50000.0 INR/Piece

Get a Price/Quote

Product Details:

Automation Grade Semi-automatic
Port Size USB 2.0
Resolution 0.01 N
Interface Type USB, RS232
Display Type Digital LCD Display
Temperature 10C to 40C
Number of Specimens Single Specimen
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Computer Interface Unit Price And Quantity

Price 50000.0 INR/Piece
Minimum Order Quantity 1 Piece

Noise Level < 60 dB at full operation
Power Consumption < 50 W
Sensor Compatibility Load cell, Pressure sensor, Displacement sensor
Input Channels Single or Dual
Cable Length 2 meters
Software Compatibility Windows 7/8/10
Communication Protocol Standard Serial Communication
Protection Overload, Short-circuit
Safety Standard CE certified
Reset Function Manual & Automatic
Calibration Factory calibrated, Calibration certificate included
Color Grey & Black
Data Storage Internal memory with data export capability
Operating System Support Windows-based systems
Dimension 285 x 200 x 75 mm
Construction Material Industrial grade ABS & Aluminum
Indicator Lamps Status and Power LEDs

Computer Interface Unit Product Specifications

Application Data Acquisition, Control & Monitoring
Measuring Range 0-500 N
Frequency 50/60 Hz
Max Height 210 mm
Capacity 500 N
Test Width 100 mm
Power Supply 220 V AC, 50/60 Hz
Equipment Type Computer Interface Unit
Usage Material testing, Laboratory Analysis
Test Range 0-500 N
Humidity 20% to 90% RH, non-condensing
Response Time < 100 ms
Features Real-time data logging, User-friendly software, Plug and Play operations
Mounting Type Table Top
Accuracy 0.5% of full scale
Operating Voltage 220 V
Port Size USB 2.0
Automation Grade Semi-automatic
Machine Weight Approximately 7 kg
Resolution 0.01 N
Interface Type USB, RS232
Display Type Digital LCD Display
Specimen Size Customizable according to test requirements
Temperature 10C to 40C
Number of Specimens Single Specimen
Test Speed Adjustable, up to 500 mm/min
Control Mode Microprocessor-based digital control
Test Stroke 120 mm

Noise Level < 60 dB at full operation
Power Consumption < 50 W
Sensor Compatibility Load cell, Pressure sensor, Displacement sensor
Input Channels Single or Dual
Cable Length 2 meters
Software Compatibility Windows 7/8/10
Communication Protocol Standard Serial Communication
Protection Overload, Short-circuit
Safety Standard CE certified
Reset Function Manual & Automatic
Calibration Factory calibrated, Calibration certificate included
Color Grey & Black
Data Storage Internal memory with data export capability
Operating System Support Windows-based systems
Dimension 285 x 200 x 75 mm
Construction Material Industrial grade ABS & Aluminum
Indicator Lamps Status and Power LEDs

Computer Interface Unit Trade Information

Payment Terms Cash Advance (CA)
Supply Ability 15-20 Piece Per Month
Delivery Time 3 Days
Main Domestic Market All India

Product Description

Owing to perfection and quality oriented approach, we have carved niche in the industry by offering an optimum quality Computer Interface Unit that is a shared boundary across which two separate components of computer system exchange information. Offered interface unit is assembled by making use of quality approved chips, wires and other allied components & pioneering technology under the guidance of our dexterous professionals. Beside this, offered Computer Interface Unit is extensively acknowledged in the market owing to its hassle free performance and long service life.

Features:

Load v/s Displacement graph
LED indication for upper & lower limits
LED indication for upwards & downwards movement status
Allow dual channel Encoder inputs to measure elongation
Windows based graphical software
Auto calibration through software.
RS232 communication.
10000 counts i.e. 0.1kg Least count on 1000 kg load cell
Suitable for tensile testing & compression testing machines

Seamless Software & Sensor Integration

This unit supports real-time data acquisition on Windows 7, 8, and 10, with plug-and-play installation. It readily connects to standard load cell, pressure, and displacement sensors, making it versatile for diverse testing environments. The intuitive software provides easy data export, allowing users to analyze results effortlessly and maintain comprehensive records for material testing and automation applications.

Rugged Build for Industrial Performance

Manufactured using industrial-grade ABS and aluminum, the unit offers durability under demanding laboratory and industrial conditions. Its CE certification, overload and short-circuit protection, and stable operation across a broad temperature (10C to 40C) and humidity (2090% RH) range provide peace of mind. With a compact footprint, low power consumption (<50W), and adjustable test speed, its suitable for benchtop or production-line integration.

Precision Measurement & Reliable Control

Achieve excellent measurement performance with an accuracy of 0.5% of full scale and 0.01 N resolution. Factory calibration and included certificates ensure compliance and ready-to-use reliability. The microprocessor-driven digital control and digital LCD display allow for precise parameter adjustments and intuitive feedback for laboratory technicians and engineers.

FAQs of Computer Interface Unit:

Q: How do I connect sensors to the Computer Interface Unit for testing?

A: The unit supports standard load cell, pressure, and displacement sensors. Simply plug your compatible sensor into the dedicated input channel. The USB 2.0 and RS232 ports facilitate quick connectivity, and the user-friendly software will recognize connected devices for immediate operation.

Q: What operating systems and communication protocols are supported?

A: This unit is designed for use with Windows 7, 8, and 10 systems. It uses standard serial communication, with USB and RS232 interfaces, enabling seamless data transfer and integration with most laboratory or industrial computers.

Q: When do I need to recalibrate the device, and is a calibration certificate provided?

A: Each unit is factory-calibrated and comes with an official calibration certificate. Recalibration is typically necessary after extended use, significant transportation, or as required by your labs quality standards. Please refer to your calibration schedule or consult the manufacturer for details.

Q: Where can the unit be installed, and what are its mounting options?

A: With its compact, table-top design and rugged construction, the Computer Interface Unit is ideal for laboratory benches, industrial facilities, or automation setups. It operates reliably within typical lab environments (temperature: 10C to 40C; humidity: 20% to 90% RH, non-condensing).

Q: What is the process for exporting recorded data for analysis?

A: After your tests, use the built-in software to export data from the units internal memory. Data can be saved in common formats for further analysis or reporting, ensuring seamless workflow integration for laboratory and quality assurance purposes.

Q: How does the unit benefit users in material testing and laboratory analysis?

A: The combination of high precision (0.5% FS), rapid response time (<100ms), and easy-to-use software streamlines testing procedures, ensures reliable results, and boosts efficiency for laboratory personnel and engineers. The versatility in sensor compatibility and adjustable testing parameters accommodate various material testing protocols.

Q: Which protections does the device offer to ensure safe operation?

A: The Computer Interface Unit is equipped with overload and short-circuit protection, indicator LEDs for status and power, and meets CE safety standards, ensuring a safe operating environment even during intensive laboratory or industrial material testing.
